JH-D2011
JH-D2011

Micro-CMTS is tailor made for distributive CMTS deployment; it can be installed on those optical nodes located at housing estate,buildings, and hotels and so on. It provides one more choice for operators. Micro-CMTS

JH-D2011 derives its name from the exquisite volume (as small as an A4 size paper).



◆Euro-DOCSIS/DOCSIS1.1,compatible with DOCSIS2.0/1.1/1/0 Cable Modem

◆1 downstream channel, 1 upstream channel

◆Built-in all channel up converters, you may make any setting depends on practical needs according to the channel spare status

Embedded DHCP/TFTP server,no needs for other server

◆DHCP relay-agent function, You can assign IP address for CM at the central machine room

◆Upstream frequency point agility, the frequency jumping will be done automatically according to strategy to avoid the noise interference

◆Upstream receiving power level adjustable: -26~+2dBmV

◆Both CM & CPE could choose working mode at layer2, layer3 and even mixed mode of layer 2 & layer 3

◆Support PPPoE dialup

◆Can be managed by CLI,COM and SNMP via remote login

◆Exquisite volume, could be installed on iron boxes or hanging on the wall

◆Cost effective, come with convenient network management software (NMS)
